EKF
Distribution terminal KSR with double screw 2x35/2x25 yellow/green PROxima EKF ksr-2.35-2.25-y-green
SKU: ksr-2.35-2.25-y-green
ETIM: EC000897
717 ₽
Price list (incl. VAT):
1344 ₽
Preorder
EKF PROxima series are designed for connecting and branching phase, neutral, and ground conductors with a cross-section of up to 35 mm2.
Thanks to these terminals, a conductor can be secured with two screws, which increases the contact area and ensures enhanced fixation.
Two pairs of holes with different diameters allow for transitioning to a different cross-section.
| Version tested for explosion protection "Ex e" | No |
| Internally linked levels | No |
| Minimum possible mounting height | 37 мм |
| Length | 55 мм |
| Housing insulation material | Polyamide (PA) |
| Rated voltage | 400 В |
| Rated current In | 125 А |
| Closing plate can be fitted if required | No |
| Operating temperature | 80 град.C |
| Operating temperature from | -40 град.C |
| Connection position | Side |
| Flexible stranded conductor cross-section up to | 35 кв.мм |
| Stranded flexible conductor cross-section from | 1.5 кв.мм |
| Solid conductor cross-section to | 35 кв.мм |
| Solid conductor cross-section from | 1.5 кв.мм |
| Mounting method | DIN rail |
| Electrical connection type 1 | Screw connection |
| Colour | Yellow-green |
| Color | Yellow-green |
| Width/connection pitch | 23 мм |
