Systeme Electric

ATLASDESIGN SOCKET with grounding and shutters with cover, 16A, IP20, mechanism, WHITE

SKU: ATN000146

ETIM: EC000125

Price on request

Preorder

Description Specifications Reviews

Special power supply	No special power supply required
RAL number (similar)	9003
Antibacterial	Yes
Supplied with plug (connector)	No
Material type/grade	Thermoplastic
Phase selection	No (without)
Device height	71 мм
Device depth	43 мм
Differential current protection	No
For heavy duty (per VDE)	No
Contact protection	Yes
Overvoltage protection	No
Protective surface coating	Untreated
Round protective grounding contact (pin)	Yes
Insulated installation	Yes
Design	With SCHUKO earthing contact
Number of active contacts (round)	2
Number of active contacts (flat)	0
Number of seats	1
Number of modules (modular system)	0
Number of switchable outlets	0
Number of phases	1
Material	Plastic
Extraction mechanism	No
Minimum depth of recessed mounting box	43 мм
Halogen-free	Yes
Rated voltage	250 В
Rated current	16 А
Rated leakage current	0 мА
Labelling surface	No
Suitable for ingress protection IP	IP20
Transparent	No
With built-in USB charger	No
With power switch	No
With lock	No
With orientation lighting	No
With hinged cover	Yes
With illumination (mains voltage indication)	No
With signal lamp	No
With low-current fuse	No
With through-channel function	No
With central insert	No
Symbols/indication	Without marking
With shutters (touch protection)	Yes
Mounting method	Flush-mounted
Connection method	Screw terminal
Fastening type	Clamp mounting/Screw mounting
Surface type	Shiny
Impact resistance	IK01
Color	White
Frequency at	50 Гц
Frequency from	50 Гц
Device width	71 мм
