Systeme Electric
1-gang socket AtlasDesign 16A IP20 with grounded protective shutters and cover carbon mechanism SE ATN001046 Systeme Electric
SKU: ATN001046
ETIM: EC000125
728 ₽
Price list (incl. VAT):
728 ₽
Available July 31
Availability
| Warehouse | Qty | Unit | Ready for pickup | Delivery to Смоленск | |
|---|---|---|---|---|---|
|
Remote warehouse
Available
|
200 | шт | July 31 | July 31 |
Select a warehouse to order
Systeme Electric (formerly Schneider Electric) AtlasDesign series mechanism in carbon color, single socket with grounding, shutters, and cover, is suitable for 250 V networks, for a current of 16 A. The grounding contact provides additional protection against electric shock. In the presence of grounding, the electrical potential goes into the ground, protecting the person. Faceplates are made of high-quality ABS plastic, resistant to scratches and UV radiation. Thanks to the "soft touch" coating, the product is pleasant to touch.
| Special power supply | No special power supply required |
| RAL number (similar) | 9005 |
| Antibacterial | No |
| Supplied with plug (connector) | No |
| Material type/grade | Thermoplastic |
| Phase selection | No (without) |
| Device height | 71 мм |
| Device depth | 43 мм |
| Differential current protection | No |
| For heavy duty (per VDE) | No |
| Contact protection | Yes |
| Overvoltage protection | No |
| Protective surface coating | Untreated |
| Round protective grounding contact (pin) | Yes |
| Insulated installation | Yes |
| Design | With SCHUKO earthing contact |
| Number of active contacts (round) | 2 |
| Number of active contacts (flat) | 0 |
| Number of seats | 1 |
| Number of modules (modular system) | 0 |
| Number of switchable outlets | 0 |
| Number of phases | 1 |
| Material | Plastic |
| Extraction mechanism | No |
| Minimum depth of recessed mounting box | 43 мм |
| Halogen-free | Yes |
| Rated voltage | 250 В |
| Rated current | 16 А |
| Rated leakage current | 0 мА |
| Labelling surface | No |
| Suitable for ingress protection IP | IP20 |
| Transparent | No |
| With built-in USB charger | No |
| With power switch | No |
| With lock | No |
| With orientation lighting | No |
| With hinged cover | Yes |
| With illumination (mains voltage indication) | No |
| With signal lamp | No |
| With low-current fuse | No |
| With through-channel function | No |
| With central insert | No |
| Symbols/indication | Without marking |
| With shutters (touch protection) | Yes |
| Mounting method | Flush-mounted |
| Connection method | Screw terminal |
| Fastening type | Clamp mounting/Screw mounting |
| Surface type | Matte |
| Impact resistance | IK01 |
| Color | Black |
| Frequency at | 50 Гц |
| Frequency from | 50 Гц |
| Device width | 71 мм |
