LED luminaire GR070/C 2.0 30W 4000K IP54 588x588x50 for clean rooms opal polycarbonate VARTON V1-R4-00010-31000-5403640
SKU: V1-R4-00010-31000-5403640
ETIM: EC002892
11814 ₽
Preorder
The GR/C IP54 series consists of standard luminaires for Grilyato-type ceilings. All-metal body made of sheet steel with white powder coating. Mounting is carried out on Euro-hangers directly into the ceiling base through special plates fixed in the luminaire body. The luminaire has an IP54 protection rating, allowing it to be used in facilities with increased requirements for the airtightness of electrical devices.
| Without dimming | Yes |
| Supplied with lamp | Yes |
| Can be covered with thermal insulation | No |
| Built-in length | 588 мм |
| Built-in height/depth | 50 мм |
| Height/depth | 50 мм |
| 0-10 V dimming | No |
| 1-10V dimming | No |
| DALI dimming | No |
| DMX dimming | No |
| GPRS dimming | No |
| LineSwitch dimming | No |
| RF dimming | No |
| Zigbee dimming | No |
| Dimming depending on control mechanism | No |
| Voltage modulation dimming | No |
| Push-button dimming | No |
| Trailing-edge phase dimming | No |
| Leading-edge phase-cut dimming | No |
| Length | 588 мм |
| Colour rendering index | 80-89 (class 1B) |
| Grille design | No (without) |
| Glow-wire test in accordance with IEC 60695-2-11 | No (without) |
| Electric shock protection class | It seems your message was cut off. Please provide the text you would like me to translate from Russian to English, and I will follow your instructions strictly. |
| Built-in luminaire energy efficiency class | A++, A+, A (LED) |
| Number of poles | 3 |
| Power factor | .95 |
| Maximum power | 30 Вт |
| Housing material | Steel |
| Diffuser/lampshade material | Opal plastic |
| Rated voltage up to | 230 В |
| Rated voltage from | 220 В |
| Rated luminous flux | 3600 лм |
| Rated LED DC current from | 141 мА |
| Ballast included | Yes |
| Suitable for ceiling fastening | Yes |
| Suitable for wall mounting | No |
| Suitable for continuous light lines | No |
| Suitable for surface mounting | No |
| Suitable for suspended mounting | Yes |
| Suitable for monitor workplace EN 12464-1 | Yes |
| Suitable for number of light sources | 1 |
| Suitable for emergency lighting | No |
| Dimming potentiometer (built-in) | No |
| Designed for flush mounting | Yes |
| Programmable dimming | No |
| Fire protection "d" | No |
| Light distributor | Diffuser lens/optics/panel |
| DSI dimming | No |
| Current type | AC/DC |
| With motion sensor | No |
| With light sensor | No |
| With air circulation opening | No |
| Light output | Straight |
| Light distribution | Symmetrical |
| Touch dimming | No |
| Core cross-section | 2.5 кв.мм |
| Sinusoidal dimming | No |
| Manufacturer's proprietary dimming system | No |
| Connection method | Clamp contact |
| Old URL | https://sissol.ru/shop/57399-svetilnik-led-varton-grilyato-58858850-30w-4000k-ip54-dlya-chistykh-pomeshhenij-opal-polikarbonat.html |
| IP protection rating | IP54 |
| Ambient temperature up to | 40 град.C |
| Ambient temperature from | -20 град.C |
| Lamp type | Non-replaceable LED |
| Connection type | Terminating |
| Light beam angle | Extra wide beam > 80 deg |
| Impact resistance | IK02 |
| Control device | LED current-controlled device |
| Housing color | White |
| Light color | White |
| Color temperature at | 4000 К |
| Colour temperature from | 4000 К |
| Lamp base (holder) | No (without) |
| Width | 588 мм |
| Installation width | 588 мм |
| Luminaire efficiency | 120 лм/Вт |
