Circuit breaker ВА55-43-345810-20УХЛ3 1600A МРТ2-МП НР110AC РНН110DC front copper busbar Contactor 1043566

SKU: 1043566

ETIM: EC000228

336578 ₽

Preorder

Description Specifications Reviews

Main circuit connection type	Front connection
Built-in ground fault protection	No
Built-in motor drive	No
Height	452.0 мм
Depth	231.0 мм
Short-time delayed short-circuit release range	720…19200 А
Overload protection device setting range to	1600 А
Setting range of overload protection device from	480 А
Instantaneous short-circuit release setting range to	19200 А
Instantaneous short-circuit release setting range from	960 А
Design	Stationary
Number of auxiliary NO contacts	1
Number of auxiliary break contacts	1
Number of poles	3
Design	Device complete with housing
Motor drive optional	No
Rated service short-circuit breaking capacity Ics	41.25
Rated ultimate short-circuit breaking capacity Icu at 400 V, 50 Hz	55 кА
Rated voltage up to	690 В
Rated voltage from	0 В
Rated current	1600 А
Rated continuous current Iu	1600 А
Suitable for DIN-rail mounting	No
Power loss	324 Вт
With minimum voltage protection	Yes
IP protection rating	IP20
Product/component type	Moulded case circuit breaker
Main electrical circuit connection type	Screw connection
Control element type	Lever (toggle)
Width	551.0 мм
