Контактор (группа IEK)
Circuit breaker VA57-35M-340010-200A-690AC-1000A-UKHL3 Contactor L250-0107
SKU: L250-0107
ETIM: EC000228
12298 ₽
Available August 20
Availability
| Warehouse | Qty | Unit | Ready for pickup | Delivery to Smolensk | |
|---|---|---|---|---|---|
|
Manufacturer warehouse
Available
|
3 | шт | August 20 | August 20 |
Select a warehouse to order
VA57-35M is a series of circuit breakers for currents from 16 to 250 A, with a rated voltage of up to 690 V AC and 440 V DC, with a breaking capacity of up to 42 kA (at 400 V). Available in versions with adjustable thermal and/or electromagnetic release, and without thermal release. Features a wide range of accessories. Used in a wide variety of facilities.
| Main circuit connection type | Front connection |
| Built-in ground fault protection | No |
| Built-in motor drive | No |
| Height | 175.0 мм |
| Depth | 112.0 мм |
| Overload protection device setting range to | 200 А |
| Setting range of overload protection device from | 200 А |
| Instantaneous short-circuit release setting range to | 1000 А |
| Instantaneous short-circuit release setting range from | 1000 А |
| Design | Stationary |
| Number of auxiliary NO contacts | 0 |
| Number of auxiliary break contacts | 0 |
| Number of poles | 3 |
| Design | Device complete with housing |
| Motor drive optional | Yes |
| Rated service short-circuit breaking capacity Ics | 42 |
| Rated ultimate short-circuit breaking capacity Icu at 400 V, 50 Hz | 42 кА |
| Rated voltage up to | 690 В |
| Rated voltage from | 400 В |
| Rated current | 200 А |
| Rated continuous current Iu | 200 А |
| Suitable for DIN-rail mounting | No |
| Power loss | 39.3 Вт |
| With minimum voltage protection | Yes |
| Tripping system | Thermal-magnetic |
| IP protection rating | IP00 |
| Product/component type | Moulded case circuit breaker |
| Main electrical circuit connection type | Screw connection |
| Control element type | Lever (toggle) |
| Width | 112.0 мм |
