Circuit breaker ВА57-39-341310-630А-660/380AC-6300А-РМН230AC Contactor L630-0468

SKU: L630-0468

ETIM: EC000228

44561 ₽

Preorder

Description Specifications Reviews

Main circuit connection type	Front connection
Built-in ground fault protection	No
Built-in motor drive	No
Height	145.0 мм
Depth	250.0 мм
Overload protection device setting range to	630 А
Setting range of overload protection device from	630 А
Instantaneous short-circuit release setting range to	6300 А
Instantaneous short-circuit release setting range from	6300 А
Trip indicator present	No
Design	Stationary
Number of auxiliary NO contacts	0
Number of auxiliary changeover contacts	0
Number of auxiliary break contacts	0
Number of poles	3
Design	Device complete with housing
Motor drive optional	No
Rated service short-circuit breaking capacity Ics	35
Rated ultimate short-circuit breaking capacity Icu at 400 V, 50 Hz	35 кА
Rated voltage up to	660 В
Rated voltage from	0 В
Rated current	630 А
Rated continuous current Iu	630 А
Suitable for DIN-rail mounting	No
Power loss	150 Вт
With minimum voltage protection	Yes
Tripping system	Thermal-magnetic
IP protection rating	IP20
Product/component type	Moulded case circuit breaker
Main electrical circuit connection type	Screw connection
Control element type	Lever (toggle)
Width	145.0 мм
