DEKraft
Motor protection circuit breaker 3p 100A 36kA VA-303 DEKraft 22810DEK
SKU: 22810DEK
ETIM: EC000228
8290 ₽
Preorder
Molded case circuit breakers in the VA-300 series, type VA-303M with non-adjustable thermomagnetic trip for motor load protection; 3P; rated current 100A. Devices are used in power, residential, industrial, transport, and other facilities.
| Trip indicator present | Yes |
| Number of auxiliary NO contacts | 0 |
| Number of auxiliary break contacts | 0 |
| Number of poles | 3 |
| Design | Built-in fixed-mounted device |
| Motor drive optional | Yes |
| Rated ultimate short-circuit breaking capacity Icu at 400 V, 50 Hz | 36 кА |
| Rated voltage up to | 415 В |
| Rated voltage from | 400 В |
| Rated continuous current Iu | 100 А |
| Suitable for DIN-rail mounting | No |
| With minimum voltage protection | No |
| IP protection rating | IP20 |
