YON MD63 modular single-pole circuit breaker rated at 16 A with trip characteristic "D" and breaking capacity of 10 kA is designed for use in electrical circuits with voltage up to 400 V AC at 50 Hz, for their protection against overloads and short circuits, and for conducting current in normal operating switching modes of the specified circuits. An independent release in a separate module and auxiliary contacts in a separate module can be attached to the circuit breaker. The independent release and auxiliary contacts are ordered separately and installed on the circuit breakers by the consumer as needed.
| Additional equipment possible | Yes |
| Mounting installation depth | 75 мм |
| Overvoltage category | 4 |
| Current limiting class | 3 |
| Number of protected poles | 1 |
| Rated short-circuit breaking capacity Icu IEC 60898 at 230 V | 10 кА |
| Rated short-circuit breaking capacity Icu IEC 60898 at 400 V | 10 кА |
| Rated impulse voltage | 4 кВ |
| Rated voltage | 230 В |
| Rated insulation voltage Ui | 230 В |
| Rated current | 16 А |
| Total number of poles | 1 |
| Ambient operating temperature to | 40 град.C |
| Ambient operating temperature from | -60 град.C |
| Current type | Alternating current (AC) |
| With switched neutral conductor | Yes |
| Flexible stranded conductor cross-section up to | 25 кв.мм |
| Stranded flexible conductor cross-section from | 25 кв.мм |
| Solid conductor cross-section to | 25 кв.мм |
| Solid conductor cross-section from | 25 кв.мм |
| Pollution degree (number) | 3 |
| IP protection rating | IP20 |
| Tripping characteristic | It seems your message was cut short. Please provide the text you would like me to translate from Russian to English, and I will follow your instructions strictly. |
| Frequency | 50 Гц |
| Frequency at | 50 Гц |
| Frequency from | 50 Гц |
| Width in modular units | 1 |
