Ammeter E47 75/5A accuracy class 1.5 72x72mm IEK IPA10-6-0075-E

Used in low-voltage switchgear in distribution electrical networks of residential, commercial, and industrial facilities. E47 ammeters - analog electromagnetic measuring instruments - are designed to measure current in AC electrical circuits. Comply with the requirements of GOST 30012.1, 8711, 22261; GOST R 52319, 51522, 51317.3.2, 51317.3.3 and are manufactured according to technical specifications TU 4223-023-18461115-2008. E47 measuring instruments are included in the State Register of Measuring Instruments. A type approval certificate for measuring instruments has been obtained. Principle of operation: E47 ammeters belong to instruments with an electromagnetic system. They consist of a round coil with movable and stationary cores placed inside. When current flows through the coil windings, a magnetic field is created that magnetizes both cores. As a result, like poles of the cores repel each other, and the movable core rotates the needle axis. To protect against the negative influence of external magnetic fields, the coil and cores are protected by a metal shield.
