IEK
ARMAFIX Spring terminal CX10-3 10mm2 three-contact gray IEK AF-CT40-00-3-K03-010
SKU: AF-CT40-00-3-K03-010
ETIM: EC000897
16,000 ₽
Get back 160 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Order multiple: 50 шт
Analogues by specifications
Stock by warehouse
No description available
Version tested for explosion protection "Ex e"
No
Minimum possible mounting height
49.3 мм
Length
97.60 мм
Length
97.60 мм
Number of terminals per level
3
Number of poles
1
Number of levels
1
Housing insulation material
Thermoplastic
Rated voltage
1000 В
Rated current In
57 А
Closing plate can be fitted if required
Yes
Operating temperature
85 град.C
Operating temperature from
-40...85 град.C
Connection position
Top
Stranded wire cross-section with ferrule
0.2...10 мм²
Flexible stranded conductor cross-section up to
10 кв.мм
Stranded flexible conductor cross-section from
0.2...10 кв.мм
Solid conductor cross-section to
10 кв.мм
Solid conductor cross-section from
0.2...10 кв.мм
Extra-fine-stranded flexible conductor cross-section without ferrule, from
0.2...10 кв.мм
Mounting method
DIN rail (standard) 35 mm
Electrical connection type 1
Spring clamp connection
Electrical connection type 2
Spring clamp connection
Colour
Grey
Color
Grey
Width/connection pitch
10.0 мм
