IEK
ARMAFIX Spring terminal CX4 BU 4mm2 feed-through blue IEK AF-CT40-00-K07-004
SKU: AF-CT40-00-K07-004
ETIM: EC000897
53 ₽
Analogues by specifications
Stock by warehouse
No description available
Version tested for explosion protection "Ex e"
No
Minimum possible mounting height
37.5 мм
Length
55.00 мм
Number of terminals per level
2
Number of poles
1
Number of levels
1
Housing insulation material
Thermoplastic
Rated voltage
1000 В
Rated current In
32 А
Closing plate can be fitted if required
Yes
Operating temperature
85 град.C
Operating temperature from
-40...85 град.C
Connection position
Top
Stranded wire cross-section with ferrule
0.2...4.0 мм²
Flexible stranded conductor cross-section up to
4 кв.мм
Stranded flexible conductor cross-section from
0.2...4.0 кв.мм
Solid conductor cross-section to
6 кв.мм
Solid conductor cross-section from
0.2...6.0 кв.мм
Extra-fine-stranded flexible conductor cross-section without ferrule, from
0.2...4.0 кв.мм
Mounting method
DIN rail (standard) 35 mm
Electrical connection type 1
Spring clamp connection
Electrical connection type 2
Spring clamp connection
Color
Blue/light blue
Colour
Blue/light blue
Width/connection pitch
6.0 мм
0
★★★★★
0 reviews
No reviews yet. Be the first!
Leave a review
