ARMAFIX Screw terminal CY10 PE Ex IEK AF-CT30-01-K52-010-EX
SKU: AF-CT30-01-K52-010-EX
ETIM: EC000901
17,550 ₽
Get back 175 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Order multiple: 50 шт
Analogues by specifications
Stock by warehouse
CY terminal blocks have a number of design features that simplify installation. The screw clamp system guarantees secure conductor fixation. A uniform size of end plates and circuit separators allows for minimizing the spare parts inventory. CY series terminal blocks are manufactured in accordance with Directive 2014/34/EU "Equipment and protective systems intended for use in potentially explosive atmospheres" and have the corresponding certificate; therefore, CY series terminal blocks have the explosion protection mark (EX) directly on the terminal body.
Length
50 мм
Length
50 мм
Flammability class of insulation material in accordance with UL57
V0
Number of terminals per level
2
Number of levels
1
Housing insulation material
Thermoplastic
Availability of PEN terminal
Yes
Rated frequency
50
Rated insulation voltage Ui
630 В
Closing plate can be fitted if required
Yes
Operating temperature
110 град.C
Operating temperature from
-60...110 град.C
Connection position
Side (transverse)
Stranded wire cross-section with ferrule
0.2...10 мм²
Flexible stranded conductor cross-section up to
10 кв.мм
Stranded flexible conductor cross-section from
0.2...10 кв.мм
Solid conductor cross-section to
10 кв.мм
Solid conductor cross-section from
0.2...10 кв.мм
Extra-fine-stranded flexible conductor cross-section without ferrule, from
0.2...10 кв.мм
Mounting method
DIN rail (standard) 35 mm
Electrical connection type 1
Screw connection
Electrical connection type 2
Screw connection
Color
Yellow-green
Colour
Yellow-green
Width/connection pitch
10 мм
