ARMAT AR-A6V TY63 4P W VR Air circuit breaker 125kA trip unit TY 6300A 4P withdrawable with accessories ~220-240V: shunt trip, closing coil, motor operator IEK AR-ACB-4VH-125-6300A-TYCF
SKU: AR-ACB-4VH-125-6300A-TYCF
ETIM: EC000228
10,717,437 ₽
Get back 107,174 ₽ in points
Analogues by specifications
No description available
Main circuit connection type
Rear connection
Built-in motor drive
Yes
Height
475.0 мм
Height
475.0 мм
Altitude above sea level
< 2000
Depth
390.0 мм
Overload protection device setting range to
6300 А
Setting range of overload protection device from
2520...6300 А
Instantaneous short-circuit release setting range to
100000 А
Instantaneous short-circuit release setting range from
6300...100000 А
Auxiliary device factory-installed
Shunt release (for power circuit breakers)
Design
Withdrawable
Number of auxiliary NO contacts
0
Number of auxiliary changeover contacts
6
Number of auxiliary break contacts
0
Number of poles
4
Design
Other
Mechanical endurance without maintenance
12500
Motor drive optional
No
Electronic release available
Yes
Rated impulse withstand voltage
12
Rated short-time withstand current Icw for 1 s
125
Rated service short-circuit breaking capacity Ics
125
Rated ultimate short-circuit breaking capacity Icu at 400 V, 50 Hz
125 кА
Rated insulation voltage Ui
1250 В
Rated voltage up to
690 В
Rated voltage from
690...690 В
Rated current
6300 А
Rated continuous current Iu
6300 А
Suitable for DIN-rail mounting
No
Power loss
1200 Вт
Operating mode
Continuous
With minimum voltage protection
Yes
Tripping system
Electronic
IP protection rating
IP30
Product/component type
Air circuit breaker
Main electrical circuit connection type
Bolted connection
Control element type
Other
Mains supply frequency
50 Гц
Width
966.0 мм
Electrical endurance without maintenance at AC 690V
1000
