IEK
ARMAT Miniature circuit breaker without thermal release M10N-MA 3P D 3A IEK AR-M10N-MA-3-D003
SKU: AR-M10N-MA-3-D003
ETIM: EC000042
6,809 ₽
Get back 68 ₽ in points
Analogues by specifications
ARMAT M10N MA series circuit breakers without thermal release are designed to protect circuits from short circuits. The main application area of the circuit breaker is emergency ventilation and fire extinguishing systems. The product range includes devices with C and D tripping characteristics for rated currents from 1A to 63A with 1P, 2P, 3P number of poles. The rated maximum breaking capacity of ARMAT M10N MA series circuit breakers is 10 kA.
Weight per pole
0.12
Additional equipment possible
Yes
Busbar connection capability
PIN (pin), FORK (fork)
Electric shock protection class
0
Number of protected poles
3
Number of poles
3
Maximum supply cable cross-section
25 кв.мм
Mech. endurance
20000
Explosion protection present
Without explosion protection
Availability of residual current release
No
Thermal release available
No
Electromagnetic release present
Yes
Electronic release available
No
Rated impulse withstand voltage
6
Rated short-circuit breaking capacity Icu IEC 60898 at 230 V
10.0 кА
Rated short-circuit breaking capacity Icu IEC 60898 at 400 V
10.0 кА
Rated breaking capacity in accordance with EN 60898
10 кА
Rated impulse voltage
6 кВ
Rated voltage
400 В
Rated insulation voltage Ui
500 В
Rated current
3.0 А
Total number of poles
3
Ambient operating temperature to
70 град.C
Ambient operating temperature from
-40...70 град.C
Operating mode
Continuous-S1
Repairability
No
Current type
Alternating current (AC)
Flexible stranded conductor cross-section up to
25 кв.мм
Stranded flexible conductor cross-section from
1...25 кв.мм
Solid conductor cross-section to
25 кв.мм
Solid conductor cross-section from
1...25 кв.мм
Tripping system
Electromagnetic
Mounting method
On DIN rail
Pollution degree (number)
2
IP protection rating
IP20
Connection type
Screw connection
Tripping characteristic
It seems your message was cut short. Please provide the text you would like me to translate from Russian to English, and I will follow your instructions strictly.
Frequency
50 Гц
Frequency at
50 Гц
Frequency from
50 Гц
Width in modular units
3
Electrical endurance
10000
