ARMAT Circuit Breaker M06N 3P D 6A IEK AR-M06N-3-D006
SKU: AR-M06N-3-D006
ETIM: EC000042
3071 ₽
Price list (incl. VAT):
4094 ₽
Available August 20
Order multiple: 4
Availability
| Warehouse | Qty | Unit | Ready for pickup | Delivery to Smolensk | |
|---|---|---|---|---|---|
|
Manufacturer warehouse
Available
|
6 | шт | August 20 | August 20 |
Select a warehouse to order
ARMAT M06N series circuit breakers are designed to protect circuits from overload and short circuits. The product range includes devices with B, C, D tripping characteristics and rated currents from 0.5 to 63 A. The rated breaking capacity of ARMAT M06N series circuit breakers is 6 kA. The ultimate breaking capacity varies depending on the rating from 10 to 50 kA.
| Weight per pole | 0.116 |
| Additional equipment possible | Yes |
| Busbar connection capability | PIN (pin), FORK (fork) |
| Release response time in short-circuit range tm | 0.1 |
| Electric shock protection class | 0 |
| Current limiting class | 3 |
| Number of protected poles | 3 |
| Number of poles | 3 |
| Number of power poles | 3 |
| Maximum supply cable cross-section | 25 кв.мм |
| Mech. endurance | 20000 |
| Explosion protection present | Without explosion protection |
| Availability of residual current release | No |
| Thermal release available | Yes |
| Electromagnetic release present | Yes |
| Electronic release available | No |
| Rated impulse withstand voltage | 6 |
| Rated short-circuit breaking capacity Icu IEC 60898 at 230 V | 6.0 кА |
| Rated short-circuit breaking capacity Icu IEC 60898 at 400 V | 6.0 кА |
| Rated breaking capacity in accordance with EN 60898 | 6 кА |
| Rated voltage | 400 В |
| Rated insulation voltage Ui | 500 В |
| Rated current | 6.0 А |
| Total number of poles | 3 |
| Power loss | 9.0 Вт |
| Ambient operating temperature to | 70 град.C |
| Ambient operating temperature from | -40...70 град.C |
| Operating mode | Continuous-S1 |
| Repairability | No |
| Current type | Alternating current (AC) |
| With switched neutral conductor | No |
| Tripping system | Thermal, electromagnetic |
| Mounting method | On DIN rail |
| IP protection rating | IP20 |
| Application area | Domestic |
| Mounting rail type | 35x7.5 |
| Connection type | Screw connection |
| Tripping characteristic | It seems your message was cut short. Please provide the text you would like me to translate from Russian to English, and I will follow your instructions strictly. |
| Frequency | 50 Гц |
| Frequency at | 50 Гц |
| Frequency from | 50 Гц |
| Width in modular units | 3 |
| Electrical endurance | 10000 |
