IEK
ARMAT Circuit breaker M06N-DC 3P Z 10A IEK AR-M06N-3-Z010DC
SKU: AR-M06N-3-Z010DC
ETIM: EC000042
245,560 ₽
Get back 2,455 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Order multiple: 40 шт
Analogues by specifications
No description available
Weight per pole
0.00012
Additional equipment possible
Yes
Busbar connection capability
PIN (pin), FORK (fork)
Electric shock protection class
0
Current limiting class
3
Climatic version
UKhL3
Number of protected poles
3
Number of poles
3
Maximum supply cable cross-section
25 кв.мм
Mech. endurance
20000
Explosion protection present
Without explosion protection
Availability of residual current release
No
Thermal release available
Yes
Electromagnetic release present
Yes
Rated impulse withstand voltage
6
Rated short-circuit breaking capacity Icu IEC 60898 at 230 V
6.0 кА
Rated short-circuit breaking capacity Icu IEC 60898 at 400 V
6.0 кА
Rated breaking capacity in accordance with EN 60898
6 кА
Rated impulse voltage
6 кВ
Rated voltage
750 В
Rated insulation voltage Ui
1000 В
Rated DC voltage from
750 В
Rated current
10.0 А
Total number of poles
3
Ambient operating temperature to
40 град.C
Ambient operating temperature from
-5...40 град.C
Operating mode
Continuous-S1
Repairability
No
Current type
Constant (DC)
Switch-on current type
Constant (DC)
With time delay
No
With switched neutral conductor
No
Stranded flexible conductor cross-section from
25 кв.мм
Solid conductor cross-section from
25 кв.мм
Tripping system
Thermal, electromagnetic
Mounting method
On DIN rail
Pollution degree (number)
2
IP protection rating
IP20
Application area
Industrial and domestic
Mounting rail type
TN-35
Connection type
Screw connection
Tripping characteristic
Other
Frequency from
- Гц
Width in modular units
54
Electrical endurance
6000
