IEK
ARMAT Circuit breaker M06N-DC 3P Z 32A IEK AR-M06N-3-Z032DC
SKU: AR-M06N-3-Z032DC
ETIM: EC000042
11,112 ₽
Get back 111 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Analogues by specifications
ARMAT M06N-DC series automatic circuit breakers are designed for switching direct current electrical circuits with a nominal operating voltage of up to 1000 V. They protect against short-circuit and overload currents, and also perform control and sectionalizing functions. PIN and FORK busbar connection options are available. The product range includes 160 versions for 16 nominal currents from 0.5 to 63 A.
Weight per pole
0.00012
Additional equipment possible
Yes
Busbar connection capability
PIN (pin), FORK (fork)
Electric shock protection class
0
Current limiting class
3
Climatic version
UKhL3
Number of protected poles
3
Number of poles
3
Maximum supply cable cross-section
25 кв.мм
Mech. endurance
20000
Explosion protection present
Without explosion protection
Availability of residual current release
No
Thermal release available
Yes
Electromagnetic release present
Yes
Rated impulse withstand voltage
6
Rated short-circuit breaking capacity Icu IEC 60898 at 230 V
6.0 кА
Rated short-circuit breaking capacity Icu IEC 60898 at 400 V
6.0 кА
Rated breaking capacity in accordance with EN 60898
6 кА
Rated impulse voltage
6 кВ
Rated voltage
750 В
Rated insulation voltage Ui
1000 В
Rated DC voltage from
750 В
Rated current
32.0 А
Total number of poles
3
Ambient operating temperature to
40 град.C
Ambient operating temperature from
-5...40 град.C
Operating mode
Continuous-S1
Repairability
No
Current type
Constant (DC)
Switch-on current type
Constant (DC)
With time delay
No
With switched neutral conductor
No
Stranded flexible conductor cross-section from
25 кв.мм
Solid conductor cross-section from
25 кв.мм
Tripping system
Thermal, electromagnetic
Mounting method
On DIN rail
Pollution degree (number)
2
IP protection rating
IP20
Application area
Industrial and domestic
Mounting rail type
TN-35
Connection type
Screw connection
Tripping characteristic
Other
Frequency from
- Гц
Width in modular units
54
Electrical endurance
6000
