10,870 ₽
Get back 108 ₽ in points
Analogues by specifications
No description available
Weight per pole
0.00012
Additional equipment possible
Yes
Busbar connection capability
PIN (pin), FORK (fork)
Electric shock protection class
0
Current limiting class
3
Climatic version
UKhL3
Number of protected poles
4
Number of poles
4
Maximum supply cable cross-section
25 кв.мм
Mech. endurance
20000
Explosion protection present
Without explosion protection
Availability of residual current release
No
Thermal release available
Yes
Electromagnetic release present
Yes
Rated impulse withstand voltage
6
Rated short-circuit breaking capacity Icu IEC 60898 at 230 V
6.0 кА
Rated short-circuit breaking capacity Icu IEC 60898 at 400 V
6.0 кА
Rated breaking capacity in accordance with EN 60898
6 кА
Rated impulse voltage
6 кВ
Rated voltage
1000 В
Rated insulation voltage Ui
1000 В
Rated DC voltage from
1000 В
Rated current
2.0 А
Total number of poles
4
Ambient operating temperature to
40 град.C
Ambient operating temperature from
-5...40 град.C
Operating mode
Continuous-S1
Repairability
No
Current type
Constant (DC)
Switch-on current type
Constant (DC)
With time delay
No
With switched neutral conductor
No
Stranded flexible conductor cross-section from
25 кв.мм
Solid conductor cross-section from
25 кв.мм
Tripping system
Thermal, electromagnetic
Mounting method
On DIN rail
Pollution degree (number)
2
IP protection rating
IP20
Application area
Industrial and domestic
Mounting rail type
TN-35
Connection type
Screw connection
Tripping characteristic
Other
Frequency from
Please provide the text you would like me to translate. Гц
Width in modular units
72
Electrical endurance
6000
