IEK
Modular circuit breaker 2p B 80A M10H ARMAT IEK AR-M10H-2-B080
SKU: AR-M10H-2-B080
ETIM: EC000042
2,184 ₽
Get back 21 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Analogues by specifications
Stock by warehouse
ARMAT M10H series circuit breakers are designed to protect circuits from overload and short circuits. The product range includes devices with trip characteristics B, C, D and Z, L, K for rated currents of 80 and 100 A with number of poles from 1P to 4P. The rated ultimate short-circuit breaking capacity of ARMAT M10H series circuit breakers is 10 kA. ARMAT M10H series circuit breakers comply with GOST IEC 60947-2 and GOST IEC 60898-1. The design of ARMAT M10H series circuit breakers provides double contact system separation and a double arc chute with a total of 24 de-ion plates, which doubles the voltage drop across the electric arc during switching, achieving rapid and effective arc extinction.
Weight per pole
0.2
Additional equipment possible
Yes
Busbar connection capability
PIN (pin)
Electric shock protection class
0
Number of protected poles
2
Number of poles
2
Maximum supply cable cross-section
50 mm²
Mech. endurance
20000
Availability of residual current release
No
Thermal release available
Yes
Electromagnetic release present
Yes
Electronic release available
No
Rated impulse withstand voltage
6
Rated short-circuit breaking capacity Icu IEC 60898 at 230 V
10.0 kA
Rated short-circuit breaking capacity Icu IEC 60898 at 400 V
10.0 kA
Rated breaking capacity in accordance with EN 60898
10 kA
Rated impulse voltage
6 kV
Rated voltage
230/400 V
Rated insulation voltage Ui
690 V
Rated current
80.0 A
Total number of poles
2
Ambient operating temperature to
70 °C
Ambient operating temperature from
-40...70 °C
Operating mode
Continuous-S1
Repairability
No
Current type
Alternating current (AC)
Flexible stranded conductor cross-section up to
35 mm²
Stranded flexible conductor cross-section from
1...35 mm²
Solid conductor cross-section to
50 mm²
Solid conductor cross-section from
1...50 mm²
Tripping system
Thermal, electromagnetic
Mounting method
On DIN rail
Pollution degree (number)
2
IP protection rating
IP20
Application area
Industrial and domestic
Connection type
Screw connection
Tripping characteristic
B
Frequency
50 Hz
Frequency at
50 Hz
Frequency from
50 Hz
Width in modular units
2
Electrical endurance
5000
