ARMAT Circuit Breaker M10N 2P L 5A IEK AR-M10N-2-L005
SKU: AR-M10N-2-L005
ETIM: EC000042
18788 ₽
Price list (incl. VAT):
25051 ₽
Available August 20
Order multiple: 6
Availability
| Warehouse | Qty | Unit | Ready for pickup | Delivery to Smolensk | |
|---|---|---|---|---|---|
|
Manufacturer warehouse
Available
|
48 | шт | August 20 | August 20 |
Select a warehouse to order
M10N circuit breakers are designed to protect distribution and group circuits with varying loads.
Modular circuit breakers with Z, K, L characteristics have successfully passed testing according to the IEC 60947-2 standard. They possess all the advantages of the ARMAT series modular equipment: increased housing strength, reinforced arc quenching chamber, independent trip mechanism, etc.
This type of circuit breaker is recommended for use in incoming and distribution devices for industrial and energy infrastructure facilities.
| Weight per pole | 0.118 |
| Additional equipment possible | Yes |
| Busbar connection capability | PIN (pin), FORK (fork) |
| Electric shock protection class | 0 |
| Number of protected poles | 2 |
| Number of poles | 2 |
| Maximum supply cable cross-section | 25 кв.мм |
| Mech. endurance | 20000 |
| Explosion protection present | Without explosion protection |
| Availability of residual current release | No |
| Thermal release available | Yes |
| Electromagnetic release present | Yes |
| Electronic release available | No |
| Rated impulse withstand voltage | 6 |
| Rated short-circuit breaking capacity Icu IEC 60898 at 230 V | 7.5 кА |
| Rated short-circuit breaking capacity Icu IEC 60898 at 400 V | 7.5 кА |
| Rated breaking capacity in accordance with EN 60898 | 7.5 кА |
| Rated voltage | 400 В |
| Rated insulation voltage Ui | 500 В |
| Rated current | 5.0 А |
| Total number of poles | 2 |
| Suitable for load-break switch | Yes |
| Suitable for motor protection switch | No |
| Power loss | 6.0 Вт |
| Ambient operating temperature to | 40 град.C |
| Ambient operating temperature from | -5...40 град.C |
| Operating mode | Continuous-S1 |
| Repairability | No |
| Current type | Alternating current (AC) |
| Switch-on current type | Alternating current (AC) |
| With switched neutral conductor | Yes |
| Flexible stranded conductor cross-section up to | 25 кв.мм |
| Stranded flexible conductor cross-section from | 1...25 кв.мм |
| Solid conductor cross-section to | 25 кв.мм |
| Solid conductor cross-section from | 1...25 кв.мм |
| Tripping system | Thermal, electromagnetic |
| Mounting method | On DIN rail |
| IP protection rating | IP20 |
| Application area | Domestic |
| Mounting rail type | TN-35 |
| Connection type | Screw connection |
| Tripping characteristic | Other |
| Frequency | 50 Гц |
| Frequency at | 50 Гц |
| Frequency from | 50 Гц |
| Width in modular units | 2 |
| Electrical endurance | 10000 |
