Signal indicator with LED 12-30V AC/DC H 30mm red EMAS H060XK

H series signal light assembly, 30 mm, plastic material, red color, illumination contact block 12-30 V AC/DC. Operating current - 5-20 mA (12-30 V AC/DC) Operating frequency - 50 Hz Operating voltage - 12-30 V AC/DC Product – Signal light assembly Color - Red Light - LED Diameter - 30 mm Mounting diameter 22 mm Power consumption - 0.7 W Insulation voltage - (Ui) 300 V Operating temperature - -15 / + 70 °C Pollution degree - 3 Protection class - IP50 Cable cross-section area - 1.5-2.5 sq.mm. Tightening torque - 1.5 Nm Series - H Plastic Electrical service life - (min. h) 10000 • Finger protection for maximum safety. • Impact-resistant polycarbonate button lens. • Non-melting V0 PA6.6 contact blocks. • Ability to use various LED contact blocks upon request. • No tools required when installing contact blocks onto the adapter. • Minimal heating and maximum service life thanks to LED illumination. • 2 contact blocks can be installed in series. • Various marking labels in different languages and with special symbols. • Product variety that will meet all requirements.
