Generica (Группа IEK)
RCBO AVDT32 C32 GENERICA MAD25-5-032-C-30
SKU: MAD25-5-032-C-30
ETIM: EC000905
5,970 ₽
Get back 59 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Order multiple: 6 шт
Analogues by specifications
Stock by warehouse
AVDT32 residual current circuit breakers are designed to protect people from electric shock in case of insulation failure in electrical installations, to prevent fires due to leakage currents to ground, and to protect against overload and short circuits.
Recommended for protecting group lines supplying outdoor sockets, sockets, and lighting in basements and garages.
Mounting installation depth
75 мм
Current limiting class
3
Number of protected poles
1
Number of poles
2
Maximum supply cable cross-section
25 кв.мм
Availability of residual current release
No
Thermal release available
Yes
Electromagnetic release present
Yes
Electronic release available
No
Rated impulse withstand voltage
4
Rated differential making and breaking capacity
4500
Rated breaking capacity in accordance with EN 60898
6 кА
Rated breaking capacity per IEC 60947-2
4.5 кА
Rated voltage
230 В
Rated current
32 А
Rated leakage current
0.03 мА
Total number of poles
2
Breaking capacity
4.5 кА
Current type
Alternating current (AC)
With switched neutral conductor
Yes
Tripping system
Thermal, electromagnetic
Mounting method
On DIN rail
IP protection rating
IP20
Residual current type
Alternating current (AC)
Connection type
Screw connection
Tripping characteristic
C
Frequency (Hz)
50 Hz
Width in modular units
2
