Контактор (группа IEK)
Automatic circuit breaker АВ2М10С-55-41-800-МР1-УХЛ3-НР220ВAC-ПЭ220ВAC-3р3з 800A; max current trip unit МРТ1-МП; independent trip coil 220V AC; electromagnetic drive 220V AC; free contacts 3p3z Contactor 1046078
SKU: 1046078
ETIM: EC000228
541,657 ₽
Get back 5,416 ₽ in points
Analogues by specifications
No description available
Main circuit connection type
Front connection
Built-in ground fault protection
No
Built-in motor drive
Yes
Depth
297.0 мм
Short-time delayed short-circuit release range
360…10560 А
Setting range of overload protection device from
240…880 А
Instantaneous short-circuit release setting range from
480…10560 А
Design
Stationary
Climatic version
UKhL3
Number of auxiliary NO contacts
3
Number of auxiliary changeover contacts
0
Number of auxiliary break contacts
3
Number of poles
3
Design
Built-in device for built-in appliances
Motor drive optional
Yes
Electronic release available
Yes
Rated impulse withstand voltage
6
Rated ultimate short-circuit breaking capacity Icu at 400 V, 50 Hz
23 кА
Rated voltage
690 В
Rated voltage from
0...690 В
Rated current
800 А
Rated continuous current Iu
800 А
Suitable for DIN-rail mounting
No
Power loss
348 Вт
With minimum voltage protection
Yes
Tripping system
Electronic
IP protection rating
IP00
Product/component type
Moulded case circuit breaker
Main electrical circuit connection type
Bolted connection
Control element type
Other
Mains supply frequency
50/60 Гц
Width
405.0 мм
