Circuit breaker AV2M10SV-55-41-630-MP1-UKHL3-NR380VAC-3p2z 630A; max current trip unit MRT1-MP; shunt trip 380VAC; manual drive; free contacts 3p2z Contactor 1047486
SKU: 1047486
ETIM: EC000228
630,772 ₽
Get back 6,307 ₽ in points
Analogues by specifications
No description available
Main circuit connection type
Rear connection
Built-in ground fault protection
No
Built-in motor drive
No
Height
500.0 мм
Short-time delayed short-circuit release range
283,5…8316 А
Setting range of overload protection device from
189…693 А
Instantaneous short-circuit release setting range from
378…8316 А
Auxiliary device factory-installed
Shunt release (for power circuit breakers)
Design
Withdrawable
Version
Withdrawable
Climatic version
UKhL3
Number of auxiliary NO contacts
2
Number of auxiliary changeover contacts
0
Number of auxiliary break contacts
3
Number of poles
3
Design
Slot-in device (withdrawable)
Motor drive optional
No
Electronic release available
Yes
Rated impulse withstand voltage
6
Rated ultimate short-circuit breaking capacity Icu at 400 V, 50 Hz
23 кА
Rated voltage
690 В
Rated voltage from
0...690 В
Rated current
630 А
Rated continuous current Iu
630 А
Suitable for DIN-rail mounting
No
Power loss
348 Вт
With minimum voltage protection
Yes
Tripping system
Electronic
IP protection rating
IP00
Product/component type
Moulded case circuit breaker
Control element type
Extended rotary handle (wide grip)
Mains supply frequency
50/60 Гц
