Контактор (группа IEK)
Automatic circuit breaker AB2M10SV-55-41-800-MP4-UKHL3-4p4z 800A; max. trip current release MRT4-MP; manual drive; free contacts 4p4z Contactor 1000540
SKU: 1000540
ETIM: EC000228
1,261,545 ₽
Order multiple: 2 шт
Analogues by specifications
Switches are intended to replace the AVM series circuit breakers in operation and are manufactured based on the VA50-41 and VA50-43 series switches. The switches are used in AC electrical circuits with a rated voltage of up to 660 V at a frequency of 50 or 60 Hz for conducting current in normal mode and disconnecting during short circuits and overloads, as well as for infrequent (up to 10 times per day) operational switching of these circuits. The series is included in the list of domestic products according to RF Decree No. 719 (Ministry of Industry and Trade register).
AV2M4N-53-41 – non-selective for rated currents 250 and 400 A
AV2M4S-55-41 – selective for rated currents 250 and 400 A
AV2M10N-53-41 – non-selective for rated currents 800 and 1000 A
AV2M10S-55-41 – selective for rated currents 800 and 1000 A
AV2M15N-53-43 – non-selective for rated currents 1200 and 1500 A.
AV2M15S-55-43 – selective for rated currents 1200 and 1500 A.
AV2M20N-53-43 – non-selective for rated currents 1500 and 2000 A.
AV2M20S-55-43 – selective for rated currents 1500 and 2000 A.
AV2M4-56-41 – without maximum current trips for rated current 400 A.
AV2M10-56-41 - without maximum current trips for rated currents 800 and 1000 A.
AV2M15-56-43 – without maximum current trips for rated currents 1200 and 1500 A.
AV2M20-56-43 - without maximum current trips for rated currents 1500 and 2000 A.
Main circuit connection type
Front connection
Built-in ground fault protection
No
Built-in motor drive
No
Height
650.0 мм
Height
650.0 мм
Depth
550.0 мм
Short-time delayed short-circuit release range
288…9600 А
Overload protection device setting range to
800 А
Setting range of overload protection device from
240…800 А
Instantaneous short-circuit release setting range to
20000 А
Instantaneous short-circuit release setting range from
20000…20000 А
Design
Withdrawable
Number of auxiliary NO contacts
0
Number of auxiliary break contacts
0
Number of poles
3
Design
Slot-in device (withdrawable)
Motor drive optional
No
Rated service short-circuit breaking capacity Ics
23
Rated ultimate short-circuit breaking capacity Icu at 400 V, 50 Hz
23 кА
Rated voltage up to
690 В
Rated voltage from
0...690 В
Rated current
800 А
Rated continuous current Iu
800 А
Suitable for DIN-rail mounting
No
Power loss
348 Вт
With minimum voltage protection
Yes
Tripping system
Electronic
IP protection rating
IP00
Product/component type
Moulded case circuit breaker
Main electrical circuit connection type
Screw connection
Control element type
Extended rotary handle (wide grip)
Width
660.0 мм
