Контактор (группа IEK)
Automatic circuit breaker АВ2М15С-55-43-1500-МР4-УХЛ3-НР380ВAC-ПЭ220ВAC-3р3з 1500A; max current trip unit МРТ4-МП; independent trip coil 380V AC; electromagnetic drive 220V AC; free contacts 3p3z Contactor 1016143
SKU: 1016143
ETIM: EC000228
685,245 ₽
Get back 6,852 ₽ in points
Analogues by specifications
No description available
Main circuit connection type
Front connection
Built-in ground fault protection
No
Built-in motor drive
Yes
Depth
320.0 мм
Short-time delayed short-circuit release range
540…18000 А
Overload protection device setting range to
1650 А
Setting range of overload protection device from
450…1500 А
Instantaneous short-circuit release setting range to
24000 А
Instantaneous short-circuit release setting range from
6000 А
Design
Stationary
Climatic version
UKhL3
Number of auxiliary NO contacts
3
Number of auxiliary changeover contacts
0
Number of auxiliary break contacts
3
Number of poles
3
Design
Built-in device for built-in appliances
Motor drive optional
Yes
Electronic release available
Yes
Rated impulse withstand voltage
6
Rated ultimate short-circuit breaking capacity Icu at 400 V, 50 Hz
23 кА
Rated voltage
690 В
Rated voltage from
0...690 В
Rated current
1500 А
Rated continuous current Iu
1500 А
Suitable for DIN-rail mounting
No
Power loss
348 Вт
With minimum voltage protection
Yes
Tripping system
Electronic
IP protection rating
IP00
Product/component type
Moulded case circuit breaker
Main electrical circuit connection type
Bolted connection
Control element type
Other
Mains supply frequency
50/60 Гц
