EKF
RCBO AD-2 2P (S) 32A curve C 100mA type AC electronic selective 6kA PROXIMA EKF DA2-6-32-100S-pro
SKU: DA2-6-32-100S-pro
ETIM: EC000905
1,182 ₽
Get back 11 ₽ in points
Analogues by specifications
The AD-2(4) (S) EKF PROxima residual current circuit breaker (RCBO) is a device that combines the functions of a circuit breaker with a residual current device. When the circuit breaker detects a leakage current (fault) to ground or an overcurrent (overload or short circuit) in the protected network section, the device trips, leading to the disconnection of the protected network. A special feature of EKF residual current breakers is the presence of a built-in surge protection unit. AD-2 and AD-4 EKF PROxima are available in standard and selective (AD-2S, AD-4S) versions.
Mounting installation depth
74 мм
For flush mounting
Yes
False tripping protection
No
Overvoltage category
3
Current limiting class
3
Number of protected poles
2
Rated breaking capacity in accordance with EN 60898
6 кА
Rated breaking capacity per IEC 60947-2
6 кА
Rated short-circuit breaking capacity Icn per EN 61009-1
6 кА
Rated impulse voltage
6 кВ
Rated voltage
230 В
Rated insulation voltage Ui
500 В
Rated current
32 А
Rated leakage current
0.1 мА
Total number of poles
2
Ambient operating temperature to
50 град.C
Ambient operating temperature from
-25...50 град.C
Current type
AC (alternating)
With switched neutral conductor
Yes
With interlock device
No
Flexible stranded conductor cross-section up to
16 кв.мм
Stranded flexible conductor cross-section from
0...16 кв.мм
Solid conductor cross-section to
25 кв.мм
Solid conductor cross-section from
0...25 кв.мм
Pollution degree (number)
3
IP protection rating
IP20
Residual current type
AC (alternating)
Resistance to current surges
6 кА
Tripping characteristic
Without delay
Tripping characteristic
It seems your message was cut off. Please provide the text you would like me to translate from Russian to English, and I will follow your instructions strictly.
Frequency (Hz)
50/60 Hz
Width in modular units
3
0
★★★★★
0 reviews
No reviews yet. Be the first!
Leave a review
Related products
1824 ₽
EKF RCBO AVDT-63M 1P+N 18mm 25A characteristic C 10mA type A electronic 6kA PROXIMA EKF D636EA25C10
SKU: D636EA25C10
1707 ₽
DEKraft Residual current circuit breaker 2p (1P+N) C 50A 100mA type AC 4.5kA DIF-103 DEKraft 16566DEK
SKU: 16566DEK
1103 ₽
Эра Residual current circuit breaker 2P (1P+N) C 40A 100mA type AC 4.5kA AD-32 electronic protection 230V PRO D32E2C40AC100P Era B0057363
