EKF
RCBO AD-32 1P+N 16A Curve C 10mA Type AC Electronic 4.5kA PROXIMA EKF DA32-16-10-pro
SKU: DA32-16-10-pro
ETIM: EC000905
61,020 ₽
Get back 610 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Order multiple: 60 шт
Analogues by specifications
Stock by warehouse
PROXIMA LINE UPDATE
Analog article: D63N26E16C10
The AD-32 EKF PROxima differential circuit breaker is a device that combines the functions of a circuit breaker with a residual current device. When the circuit breaker detects a leakage current (fault) to ground or an overcurrent (overload current or short circuit) in the protected section of the network, the device trips, leading to the disconnection of the protected network. The AD-32 range is supplemented with AD-32 type A and AD-32 selective RCBOs.
Mounting installation depth
73 мм
For flush mounting
Yes
False tripping protection
No
Overvoltage category
3
Current limiting class
3
Number of protected poles
1
Rated short-circuit breaking capacity Icn per EN 61009-1
4.5 кА
Rated impulse voltage
6 кВ
Rated voltage
230 В
Rated insulation voltage Ui
500 В
Rated current
16 А
Rated leakage current
0.01 мА
Total number of poles
2
Ambient operating temperature from
-25...55 град.C
Current type
AC (alternating)
With switched neutral conductor
Yes
With interlock device
No
Stranded flexible conductor cross-section from
0...16 кв.мм
Solid conductor cross-section from
0...25 кв.мм
Pollution degree (number)
3
IP protection rating
IP20
Residual current type
AC (alternating)
Resistance to current surges
4.5 кА
Tripping characteristic
Without delay
Tripping characteristic
C
Frequency (Hz)
50 Hz
Width in modular units
2
