Residual current circuit breaker AD-32 1P+N 20A characteristic C 30mA type AC electronic 4.5kA PROXIMA EKF DA32-20-30-pro

SKU: DA32-20-30-pro ETIM: EC000905

56,246 ₽

Get back 562 ₽ in points

Order multiple: 60 шт

Stock by warehouse

РЦ Тула September 16 · Delivery to Smolensk Oblast on September 21 1 шт On order РЦ Москва 3 October 1 · Delivery to Smolensk Oblast on October 8 86 шт On order

Description Specifications Reviews

Mounting installation depth 73 мм

For flush mounting Yes

False tripping protection No

Overvoltage category 3

Current limiting class 3

Number of protected poles 1

Rated breaking capacity in accordance with EN 60898 4.5 кА

Rated breaking capacity per IEC 60947-2 4.5 кА

Rated short-circuit breaking capacity Icn per EN 61009-1 4.5 кА

Rated impulse voltage 6 кВ

Rated voltage 230 В

Rated insulation voltage Ui 500 В

Rated current 20 А

Rated leakage current 0.03 мА

Total number of poles 2

Ambient operating temperature to 55 град.C

Ambient operating temperature from -25...55 град.C

Current type AC (alternating)

With switched neutral conductor Yes

With interlock device No

Flexible stranded conductor cross-section up to 16 кв.мм

Stranded flexible conductor cross-section from 0...16 кв.мм

Solid conductor cross-section to 25 кв.мм

Solid conductor cross-section from 0...25 кв.мм

Pollution degree (number) 3

IP protection rating IP20

Residual current type AC (alternating)

Resistance to current surges 4.5 кА

Tripping characteristic Without delay

Tripping characteristic It seems your message was cut off. Please provide the text you would like me to translate from Russian to English, and I will follow your instructions strictly.

Frequency (Hz) 50 Hz

Width in modular units 2
