Residual current circuit breaker with overcurrent protection AD-32 1P+N 25A curve C 10mA type AC electronic 4.5kA PROXIMA EKF DA32-25-10-pro
SKU: DA32-25-10-pro
ETIM: EC000905
891 ₽
Get back 8 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Analogues by specifications
Stock by warehouse
No description available
Mounting installation depth
73 мм
For flush mounting
Yes
False tripping protection
No
Overvoltage category
3
Current limiting class
3
Number of protected poles
1
Rated breaking capacity in accordance with EN 60898
4.5 кА
Rated breaking capacity per IEC 60947-2
4.5 кА
Rated short-circuit breaking capacity Icn per EN 61009-1
4.5 кА
Rated impulse voltage
6 кВ
Rated voltage
230 В
Rated insulation voltage Ui
500 В
Rated current
25 А
Rated leakage current
0.01 мА
Total number of poles
2
Ambient operating temperature to
55 град.C
Ambient operating temperature from
-25...55 град.C
Current type
AC (alternating)
With switched neutral conductor
Yes
With interlock device
No
Flexible stranded conductor cross-section up to
16 кв.мм
Stranded flexible conductor cross-section from
0...16 кв.мм
Solid conductor cross-section to
25 кв.мм
Solid conductor cross-section from
0...25 кв.мм
Pollution degree (number)
3
IP protection rating
IP20
Residual current type
AC (alternating)
Resistance to current surges
4.5 кА
Tripping characteristic
Without delay
Tripping characteristic
C
Frequency (Hz)
50 Hz
Width in modular units
2
0
★★★★★
0 reviews
No reviews yet. Be the first!
Leave a review
Related products
1485 ₽
EKF Residual current circuit breaker AD-32 3P+N 20A characteristic C 30mA type A electronic 4.5kA PROXIMA EKF DA32-20-30-4P-a-pro
SKU: DA32-20-30-4P-a-pro
1252 ₽
DEKraft Residual current circuit breaker 2p (1P+N) D 40A 100mA type AC DIF-101 with built-in overcurrent protection DEKraft 15215DEK
SKU: 15215DEK
1387 ₽
EKF Residual current circuit breaker (RCCB) AVDT-63N 1P+N (S) 40A characteristic C 100mA type AC electronic selective 6kA PROXIMA EKF D63N26ES40C100
SKU: D63N26ES40C100
803 ₽
Generica (Группа IEK) Residual Current Circuit Breaker AD12 2P 63A 30mA GENERICA MAD15-2-063-C-030
