Residual current circuit breaker with overcurrent protection AD-4 4P 25A characteristic C 300mA type AC electronic 6kA PROXIMA EKF DA4-6-25-300-pro
SKU: DA4-6-25-300-pro
ETIM: EC000905
2,018 ₽
Get back 20 ₽ in points
Analogues by specifications
The AD-2(4) (S) EKF PROxima residual current circuit breaker (RCBO) is a device that combines the functions of a circuit breaker with a residual current device. When the circuit breaker detects a leakage current (fault) to ground or an overcurrent (overload or short circuit) in the protected network section, the device trips, leading to the disconnection of the protected network. A special feature of EKF residual current breakers is the presence of a built-in surge protection unit. AD-2 and AD-4 EKF PROxima are available in standard and selective (AD-2S, AD-4S) versions.
Mounting installation depth
74 мм
For flush mounting
Yes
False tripping protection
No
Overvoltage category
3
Current limiting class
3
Number of protected poles
4
Rated breaking capacity in accordance with EN 60898
6 кА
Rated breaking capacity per IEC 60947-2
6 кА
Rated short-circuit breaking capacity Icn per EN 61009-1
6 кА
Rated impulse voltage
6 кВ
Rated voltage
400 В
Rated insulation voltage Ui
500 В
Rated current
25 А
Rated leakage current
0.3 мА
Total number of poles
4
Ambient operating temperature to
50 град.C
Ambient operating temperature from
-25...50 град.C
Current type
AC (alternating)
With switched neutral conductor
Yes
With interlock device
No
Flexible stranded conductor cross-section up to
16 кв.мм
Stranded flexible conductor cross-section from
0...16 кв.мм
Solid conductor cross-section to
25 кв.мм
Solid conductor cross-section from
0...25 кв.мм
Pollution degree (number)
3
IP protection rating
IP20
Residual current type
AC (alternating)
Resistance to current surges
6 кА
Tripping characteristic
Without delay
Tripping characteristic
It seems your message was cut off. Please provide the text you would like me to translate from Russian to English, and I will follow your instructions strictly.
Frequency (Hz)
50/60 Hz
Width in modular units
5
0
★★★★★
0 reviews
No reviews yet. Be the first!
Leave a review
Related products
1519 ₽
EKF Residual current circuit breaker AD-32 1P+N 6A characteristic C 30mA type A electronic 6kA PROXIMA EKF DA32-6-6-30-a-pro
SKU: DA32-6-6-30-a-pro
1422 ₽
DEKraft Residual current circuit breaker 2p C 60A 30mA type AC 4.5kA DIF-101 6mod. DEKraft 15009DEK
SKU: 15009DEK
873 ₽
КЭАЗ Residual current circuit breaker 2p C 20A 30mA type AC 4.5kA АД12-22C20-AC УХЛ4 КЭАЗ 318739
SKU: 318739
1628 ₽
КЭАЗ Residual current circuit breaker 4p C 10A 10mA type AC 4.5kA АД14-41C10-AC УХЛ4 КЭАЗ 318751
