EKF
Residual current circuit breaker with overcurrent protection AD-4 4P 40A characteristic C 300mA type AC electronic 4.5kA PROXIMA EKF DA4-40-300-pro
SKU: DA4-40-300-pro
ETIM: EC000905
1,310 ₽
Get back 13 ₽ in points
Analogues by specifications
The AD-2(4) (S) EKF PROxima residual current circuit breaker (RCBO) is a device that combines the functions of a circuit breaker with a residual current device. When the circuit breaker detects a leakage current (fault) to ground or an overcurrent (overload or short circuit) in the protected network section, the device trips, leading to the disconnection of the protected network. A special feature of EKF residual current breakers is the presence of a built-in surge protection unit. AD-2 and AD-4 EKF PROxima are available in standard and selective (AD-2S, AD-4S) versions.
Mounting installation depth
45 мм
For flush mounting
Yes
False tripping protection
No
Overvoltage category
3
Current limiting class
3
Number of protected poles
4
Rated short-circuit breaking capacity Icn per EN 61009-1
4.5 кА
Rated impulse voltage
6 кВ
Rated voltage
400 В
Rated insulation voltage Ui
500 В
Rated current
40 А
Rated leakage current
0.3 мА
Total number of poles
2
Ambient operating temperature from
-40...50 град.C
Current type
AC (alternating)
With switched neutral conductor
Yes
With interlock device
No
Stranded flexible conductor cross-section from
0...16 кв.мм
Solid conductor cross-section from
0...25 кв.мм
Pollution degree (number)
3
IP protection rating
IP20
Residual current type
AC (alternating)
Resistance to current surges
4.5 кА
Tripping characteristic
Without delay
Tripping characteristic
It seems your message was cut off. Please provide the text you would like me to translate from Russian to English, and I will follow your instructions strictly.
Frequency (Hz)
50 Hz
Width in modular units
7.5
