EKF
RCBO AD-4 4P 16A curve C 10mA type AC electronic 6kA PROXIMA EKF DA4-6-16-10-pro
SKU: DA4-6-16-10-pro
ETIM: EC000905
2,063 ₽
Get back 20 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Analogues by specifications
No description available
Mounting installation depth
74 mm
For flush mounting
Yes
False tripping protection
No
Overvoltage category
3
Current limiting class
3
Number of protected poles
4
Rated breaking capacity in accordance with EN 60898
6 kA
Rated breaking capacity per IEC 60947-2
6 kA
Rated short-circuit breaking capacity Icn per EN 61009-1
6 kA
Rated impulse voltage
6 kV
Rated voltage
400 V
Rated insulation voltage Ui
500 V
Rated current
16 A
Rated leakage current
0.01 mA
Total number of poles
4
Ambient operating temperature to
50 °C
Ambient operating temperature from
-25...50 °C
Current type
AC (alternating)
With switched neutral conductor
Yes
With interlock device
No
Flexible stranded conductor cross-section up to
16 mm²
Stranded flexible conductor cross-section from
0...16 mm²
Solid conductor cross-section to
25 mm²
Solid conductor cross-section from
0...25 mm²
Pollution degree (number)
3
IP protection rating
IP20
Residual current type
AC (alternating)
Resistance to current surges
6 kA
Tripping characteristic
Without delay
Tripping characteristic
C
Frequency (Hz)
50/60 Hz
Width in modular units
5
