EKF
Residual current circuit breaker with overcurrent protection RCBO AVDT-63 1P+N 25A characteristic C 30mA type A electronic 6kA EKF PROXIMA DA63-25-30e
SKU: DA63-25-30e
ETIM: EC000905
1,192 ₽
Get back 11 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Analogues by specifications
Stock by warehouse
No description available
Mounting installation depth
72 мм
For flush mounting
Yes
False tripping protection
No
Overvoltage category
3
Current limiting class
3
Number of protected poles
1
Rated breaking capacity in accordance with EN 60898
6 кА
Rated breaking capacity per IEC 60947-2
6 кА
Rated short-circuit breaking capacity Icn per EN 61009-1
6 кА
Rated impulse voltage
6 кВ
Rated voltage
230 В
Rated insulation voltage Ui
500 В
Rated current
25 А
Rated leakage current
0.03 мА
Total number of poles
2
Ambient operating temperature to
55 град.C
Ambient operating temperature from
-25...55 град.C
Current type
AC (alternating)
With switched neutral conductor
Yes
With interlock device
No
Flexible stranded conductor cross-section up to
16 кв.мм
Stranded flexible conductor cross-section from
0...16 кв.мм
Solid conductor cross-section to
25 кв.мм
Solid conductor cross-section from
0...25 кв.мм
Pollution degree (number)
3
IP protection rating
IP20
Residual current type
A
Resistance to current surges
6 кА
Tripping characteristic
Without delay
Tripping characteristic
C
Frequency (Hz)
50/60 Hz
Width in modular units
2
0
★★★★★
0 reviews
No reviews yet. Be the first!
Leave a review
Related products
639 ₽
TDM ELECTRIC AVDT 32 2P(1P+N) B25A 30mA 4.5kA type AC TDM SQ0202-0521
SKU: SQ0202-0521
1540 ₽
EKF Residual Current Circuit Breaker AVDT-63N 1P+N 6A characteristic C 10mA type AC electronic 6kA PROXIMA EKF D63N26E6C10
SKU: D63N26E6C10
1012 ₽
Generica (Группа IEK) Residual Current Circuit Breaker AD12 2P 50A 100mA GENERICA MAD15-2-050-C-100
SKU: MAD15-2-050-C-100
1694 ₽
IEK KARAT Residual Current Circuit Breaker (RCCB) AVDT32 C25 10mA type A 4.5kA IEK KA-VD10-1-025-C-010-A-1
