EKF
Residual Current Circuit Breaker RCBO AVDT-63N 3P+N 16A characteristic C 30mA type AC electronic 6kA PROXIMA EKF D63N46E16C30
SKU: D63N46E16C30
ETIM: EC000905
2764 ₽
Analogues by specifications
Stock by warehouse
EKF АВДТ-63N PROXIMA RCBO is a device that combines the functions of a circuit breaker with an electromechanical or electronic RCCB. When the circuit breaker detects a leakage current (fault) to ground or an overcurrent (overload or short circuit) in the protected network section, the device trips, resulting in the disconnection of the protected network. The special lever design provides device informativeness, indicating the cause of the trip (only part of the lever is down – short circuit or overload, both parts of the lever are down – leakage current). A feature of this АВДТ series is the improved design. These breakers have plastic covers that close access to the screw terminals and serve for sealing the screw terminals, which excludes unauthorized access to the conductors. EKF АВДТ-63N PROXIMA RCBO circuit breakers comply with GOST IEC 61009-1. Commutation with aluminum and copper conductors is possible.
Mounting installation depth
72 мм
For flush mounting
Yes
False tripping protection
No
Overvoltage category
3
Current limiting class
3
Number of protected poles
3
Rated breaking capacity per IEC 60947-2
6 кА
Rated short-circuit breaking capacity Icn per EN 61009-1
6 кА
Rated impulse voltage
6 кВ
Rated voltage
400 В
Rated insulation voltage Ui
500 В
Rated current
16 А
Rated leakage current
0.03 мА
Total number of poles
4
Ambient operating temperature to
50 град.C
Ambient operating temperature from
-25...50 град.C
Current type
AC (alternating)
With switched neutral conductor
Yes
With interlock device
No
Flexible stranded conductor cross-section up to
16 кв.мм
Stranded flexible conductor cross-section from
0...16 кв.мм
Solid conductor cross-section to
25 кв.мм
Solid conductor cross-section from
0...25 кв.мм
Pollution degree (number)
3
IP protection rating
IP20
Residual current type
AC (alternating)
Resistance to current surges
6 кА
Tripping characteristic
Without delay
Tripping characteristic
It seems your message was cut off. Please provide the text you would like me to translate from Russian to English, and I will follow your instructions strictly.
Frequency (Hz)
50/60 Hz
Width in modular units
4
0
★★★★★
0 reviews
No reviews yet. Be the first!
Leave a review
Related products
699 ₽
Legrand AVDT DX3 4P C50A 30mA-AC 7M LEGRAND 411191
SKU: 411191
8825 ₽
EKF Residual current circuit breaker DVA-6 1P+N 32A characteristic B 30mA type AC electromechanical 6kA AVERES EKF rcbo6-1pn-32B-30-ac-av
SKU: rcbo6-1pn-32B-30-ac-av
3426 ₽
DEKraft Differential current circuit breaker 4p (3P+N) D 63A 30mA type AC 4.5kA DIF-103 DEKraft 16693DEK
