Residual current circuit breaker DVA-10 1P+N 32A characteristic C 100mA type A electromechanical 10kA AVERES EKF rcbo10-1pn-32C-100-a-av
SKU: rcbo10-1pn-32C-100-a-av
ETIM: EC000905
406,778 ₽
Get back 4,067 ₽ in points
Order multiple: 60 шт
Analogues by specifications
DVA-6 and DVA-10 series AVERES residual current circuit breakers (RCCB) are used in AC electrical circuits with a rated voltage of 230 V / 400 V and a frequency of 50 / 60 Hz.
Designed for:
• protection of people from electric shock upon accidental contact with live parts of electrical installations;
• protection of electrical equipment against insulation damage and faults;
• prevention of fires caused by leakage currents and resulting short circuits, ground faults, and earth faults;
• automatic disconnection of a section of the electrical network during overloads and short circuits.
Mounting installation depth
79 мм
For flush mounting
Yes
False tripping protection
No
Overvoltage category
3
Current limiting class
3
Number of protected poles
1
Rated breaking capacity in accordance with EN 60898
10 кА
Rated breaking capacity per IEC 60947-2
10 кА
Rated short-circuit breaking capacity Icn per EN 61009-1
10 кА
Rated impulse voltage
6 кВ
Rated voltage
230 В
Rated insulation voltage Ui
500 В
Rated current
32 А
Rated leakage current
0.1 мА
Total number of poles
2
Ambient operating temperature to
50 град.C
Ambient operating temperature from
-40...50 град.C
Current type
AC (alternating)
With switched neutral conductor
Yes
With interlock device
No
Flexible stranded conductor cross-section up to
16 кв.мм
Stranded flexible conductor cross-section from
0...16 кв.мм
Solid conductor cross-section to
25 кв.мм
Solid conductor cross-section from
0...25 кв.мм
Pollution degree (number)
3
IP protection rating
IP20
Residual current type
Please provide the text you would like me to translate.
Resistance to current surges
10 кА
Tripping characteristic
Without delay
Tripping characteristic
It seems your message was cut off. Please provide the text you would like me to translate from Russian to English, and I will follow your instructions strictly.
Frequency (Hz)
50/60 Hz
Width in modular units
2
