EKF
Residual current circuit breaker DVA-6 1P+N 16A characteristic D 100mA type A electromechanical 6kA AVERES EKF rcbo6-1pn-16D-100-a-av
SKU: rcbo6-1pn-16D-100-a-av
ETIM: EC000905
755,635 ₽
Order multiple: 60 шт
Analogues by specifications
No description available
Mounting installation depth
79 мм
For flush mounting
Yes
False tripping protection
No
Overvoltage category
3
Current limiting class
3
Number of protected poles
1
Rated breaking capacity in accordance with EN 60898
6 кА
Rated breaking capacity per IEC 60947-2
6 кА
Rated short-circuit breaking capacity Icn per EN 61009-1
6 кА
Rated impulse voltage
6 кВ
Rated voltage
230 В
Rated insulation voltage Ui
500 В
Rated current
16 А
Rated leakage current
0.1 мА
Total number of poles
2
Ambient operating temperature to
50 град.C
Ambient operating temperature from
-40...50 град.C
Current type
AC (alternating)
With switched neutral conductor
Yes
With interlock device
No
Flexible stranded conductor cross-section up to
16 кв.мм
Stranded flexible conductor cross-section from
0...16 кв.мм
Solid conductor cross-section to
25 кв.мм
Solid conductor cross-section from
0...25 кв.мм
Pollution degree (number)
3
IP protection rating
IP20
Residual current type
Please provide the text you would like me to translate.
Resistance to current surges
6 кА
Tripping characteristic
Without delay
Tripping characteristic
It seems your message was cut short. Please provide the text you would like me to translate from Russian to English, and I will follow your instructions strictly.
Frequency (Hz)
50/60 Hz
Width in modular units
2
0
★★★★★
0 reviews
No reviews yet. Be the first!
Leave a review
Related products
1823 ₽
CHINT Residual current circuit breaker 2p (1P+N) C 63A 30mA type A 6kA AVDT NXBLE-63YH C63 electronic. (R) CHINT 515322
SKU: 515322
Price on request
CHINT Residual current circuit breaker with overcurrent protection (RCCB/RCBO) NXBL-40Y 1P+N B13 100mA type A 4.5kA electromechanical (R) CHINT 519941
