EKF
Circuit breaker VA 47-100 4P 100A (D) 10kA PROXIMA EKF mcb47100-4-100D-pro
SKU: mcb47100-4-100D-pro
ETIM: EC000042
3,104 ₽
Get back 31 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Analogues by specifications
Stock by warehouse
VA 47-100 EKF PROxima circuit breakers have absorbed all the advantages of the previous model (interchangeable) and the latest innovative developments.
Additional equipment possible
Yes
Mounting installation depth
66 mm
For flush mounting
Yes
Overvoltage category
3
Current limiting class
3
Number of protected poles
4
Rated short-circuit breaking capacity Icu IEC 60898 at 230 V
10 kA
Rated short-circuit breaking capacity Icu IEC 60898 at 400 V
10 kA
Rated short-circuit breaking capacity Icu IEC 60947-2 at 230V
10 kA
Rated breaking capacity in accordance with EN 60898
10 kA
Rated impulse voltage
4 kV
Rated voltage
400 V
Rated insulation voltage Ui
660 V
Rated current
100 A
Total number of poles
4
Ambient operating temperature to
55 °C
Ambient operating temperature from
-25...55 °C
Current type
AC (alternating)
With switched neutral conductor
Yes
Flexible stranded conductor cross-section up to
25 mm²
Stranded flexible conductor cross-section from
1...25 mm²
Solid conductor cross-section to
35 mm²
Solid conductor cross-section from
1...35 mm²
Pollution degree (number)
2
IP protection rating
IP20
Tripping characteristic
D
Frequency
50 Hz
Frequency at
60 Hz
Frequency from
50...60 Hz
Width in modular units
6
