EKF
Circuit breaker 2p D 25A 15kA VA 47-125 PROxima EKF mcb47125-2-25D
SKU: mcb47125-2-25D
ETIM: EC000042
466,061 ₽
Get back 4,660 ₽ in points
Order multiple: 36 шт
Analogues by specifications
VA 47-125 PROXIMA EKF circuit breakers, thanks to their high breaking capacity of 15 kA, can be used instead of power circuit breakers. The switches have a housing width of 1.5 modules (27 mm) and are produced with rated currents up to 125 A. For reliable arc quenching, a double contact break and two arc chutes are used. Optimal conductivity is ensured by a silver-containing contact group.
Additional equipment possible
No
Mounting installation depth
82 мм
For flush mounting
Yes
Overvoltage category
3
Current limiting class
3
Number of protected poles
2
Rated short-circuit breaking capacity Icu IEC 60898 at 230 V
15 кА
Rated breaking capacity in accordance with EN 60898
15 кА
Rated impulse voltage
4 кВ
Rated voltage
230 В
Rated insulation voltage Ui
660 В
Rated current
25 А
Total number of poles
2
Ambient operating temperature to
50 град.C
Ambient operating temperature from
-25...50 град.C
Current type
AC (alternating)
With switched neutral conductor
Yes
Flexible stranded conductor cross-section up to
25 кв.мм
Stranded flexible conductor cross-section from
1...25 кв.мм
Solid conductor cross-section to
35 кв.мм
Solid conductor cross-section from
1...35 кв.мм
Pollution degree (number)
2
IP protection rating
IP20
Tripping characteristic
It seems your message was cut short. Please provide the text you would like me to translate from Russian to English, and I will follow your instructions strictly.
Frequency at
60 Гц
Frequency from
50...60 Гц
Width in modular units
3
