EKF
Modular miniature circuit breaker 3p C 25A 4.5kA VA 47-63 PROxima EKF mcb4763-3-25C-pro
SKU: mcb4763-3-25C-pro
ETIM: EC000042
487 ₽
Get back 4 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Analogues by specifications
Stock by warehouse
PROXIMA LINEUP UPDATE
Analog article: M634325C
VA 47-63 4.5 kA EKF PROxima circuit breakers are mechanical switching devices and comply with GOST R50345-2010. A feature of this series of circuit breakers is the improved design. The circuit breakers have plastic covers that block access to the screw terminal and serve for sealing the circuit breakers, which prevents unauthorized access to the conductors. The circuit breaker housing is reinforced with additional rivets to eliminate the housing separation effect. The circuit breakers are equipped with a convenient operating handle that ensures reliable operation of the products. The front panel of the circuit breakers has a color status indicator. The design of the mounting terminal ensures free installation of the circuit breaker on a DIN rail.
Additional equipment possible
Yes
Mounting installation depth
66 mm
For flush mounting
Yes
Overvoltage category
3
Current limiting class
3
Number of protected poles
3
Rated short-circuit breaking capacity Icu IEC 60898 at 400 V
4.5 kA
Rated breaking capacity in accordance with EN 60898
4.5 kA
Rated impulse voltage
4 kV
Rated voltage
400 V
Rated insulation voltage Ui
660 V
Rated current
25 A
Total number of poles
3
Ambient operating temperature to
55 °C
Ambient operating temperature from
-25...55 °C
Current type
AC (alternating)
With switched neutral conductor
No
Flexible stranded conductor cross-section up to
16 mm²
Stranded flexible conductor cross-section from
1...16 mm²
Solid conductor cross-section to
25 mm²
Solid conductor cross-section from
1...25 mm²
Pollution degree (number)
2
IP protection rating
IP20
Tripping characteristic
C
Frequency
50 Hz
Frequency at
50 Hz
Frequency from
50...50 Hz
Width in modular units
3
