VA47-29M GENERICA automatic circuit breakers are designed to protect distribution and group circuits with various loads:
– electrical appliances, lighting – switches with characteristic B,
– motors with small inrush currents (compressor, fan) – switches with characteristic C,
– motors with large inrush currents (lifting mechanisms, pumps) – switches with characteristic D.
VA47-29M automatic circuit breakers are recommended for use in input-distribution devices for residential and public buildings.
| Weight per pole | 0.085 |
| Additional equipment possible | No |
| Busbar connection capability | PIN (pin) |
| For flush mounting | Yes |
| Electric shock protection class | 0 |
| Climatic version | UKhL4 |
| Number of protected poles | 2 |
| Maximum supply cable cross-section | 25 кв.мм |
| Mech. endurance | 10000 |
| Explosion protection present | Without explosion protection |
| Availability of residual current release | No |
| Thermal release available | Yes |
| Electromagnetic release present | Yes |
| Electronic release available | No |
| Rated impulse withstand voltage | 4 |
| Rated short-circuit breaking capacity Icu IEC 60898 at 230 V | 4.5 кА |
| Rated short-circuit breaking capacity Icu IEC 60898 at 400 V | 4.5 кА |
| Rated breaking capacity in accordance with EN 60898 | 4.5 кА |
| Rated voltage | 400 В |
| Rated current | 32 А |
| Total number of poles | 2 |
| Power loss | 12.0 Вт |
| Ambient operating temperature to | 50 град.C |
| Ambient operating temperature from | -40 град.C |
| Operating mode | Continuous-S1 |
| Repairability | No |
| Current type | Alternating current (AC) |
| With time delay | No |
| With switched neutral conductor | No |
| Flexible stranded conductor cross-section up to | 25 кв.мм |
| Stranded flexible conductor cross-section from | 1 кв.мм |
| Solid conductor cross-section to | 25 кв.мм |
| Solid conductor cross-section from | 1 кв.мм |
| Tripping system | Thermal, electromagnetic |
| Mounting method | On DIN rail |
| IP protection rating | IP20 |
| Application area | Domestic |
| Mounting rail type | TN-35 |
| Tripping characteristic | Please provide the text you would like me to translate. |
| Frequency | 50 Гц |
| Frequency at | 50 Гц |
| Frequency from | 50 Гц |
| Width in modular units | 2 |
| Electrical endurance | 4000 |
