Legrand
Circuit breaker for motor protection MPX³ T32H 22A 50kA 417333 Legrand
SKU: 417333
ETIM: EC000074
2,824 ₽
Analogues by specifications
Stock by warehouse
No description available
Height
94 мм
Depth
99.6 мм
Overload protection device setting range to
22 А
Setting range of overload protection device from
14 А
Instantaneous short-circuit release setting range to
286 А
Instantaneous short-circuit release setting range from
286 А
Number of poles
3
Design
Built-in fixed-mounted device
Rated power in AC-3 mode, 230 V
4 кВт
Rated power at AC-3, 400 V
7.5 кВт
Rated ultimate breaking capacity Icu at 400V AC
50 кА
Rated voltage at
690 В
Rated voltage from
220 В
Rated continuous current Iu
22 А
With overheating protection
Yes
Tripping system
Thermomagnetic
With built-in auxiliary switch
Yes
With built-in undervoltage release
Yes
IP protection rating
IP20
Main electrical circuit connection type
Frame terminal
Control element type
Rotary switch
Phase failure sensitive
No
Width
45 мм
