ONI (Группа IEK)
Power supply OPS 220V AC/24V DC 10A 240W ONI OPS-DC24-240B
SKU: OPS-DC24-240B
ETIM: EC002540
156,130 ₽
Get back 1,561 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Order multiple: 10 шт
Analogues by specifications
Industrial power supply units ONI OPS are modern, compact, high-quality, and functional equipment for providing power to both critical and secondary consumers.
Complying with international and Russian standards for industrial equipment, it provides high-quality and stable 24V DC power to equipment with a rated power of 240W.
2nd output voltage stage to
24 В
2nd output voltage step from
24 В
Weight
0.8 кг
Load influence
1.0
Influence of supply voltage
0.5
Busbar mounting possible
Yes
Hold-up time at 100% load - input voltage 230V
20
Settling time at 100% load and 230 V input voltage
2000
Height
124 мм
Height
124 мм
Altitude above sea level
≤ 6000
Output power
240 В.А
Output power
240 Вт
Output voltage 1 at
24 В
Output voltage 1 from
24 В
Depth
127 мм
Input voltage range
AC (90...264); DC (127...370)
Output current range
0...10.00
Output voltage setting range
24...28
Overvoltage protection tripping range
28.8...31.2
Frequency range
47...63
Short-circuit protection
Yes
Insulation per GOST 12-2-091
Reinforced
Efficiency
87
Overvoltage category
2
Number of supply lines
4
Maximum output current 1
10 А
Modular design
No
Rated power at air temperature 25°C
240
Rated DC output voltage
24
Rated AC mains supply voltage 50 Hz to
264 В
Rated AC 50 Hz mains supply voltage from
220 В
Rated DC supply voltage to
370 В
Rated DC supply voltage from
- В
Rated output current
10.00 А
Relative air humidity
20...90%
Peak inrush current at 230V input voltage
60
Output current limiting threshold
103...115
Power consumption
- кВт
Max. permissible output voltage deviation
1
Connection capability
0.5...6
Supply voltage current type
AC/DC
Self-current consumption
≤ 0.035
Insulation resistance at 500V input-output
100
Insulation resistance at 500 V input-housing
100
Insulation resistance at 500V output-housing
100
Mounting method
DRA (on DIN rail)
Pollution degree
2 per GOST IEC 60947-1
IP protection rating
IP20
Temperature coefficient
±0.03% (category C per GOST IEC 61204)
Overload protection type
output current limiting; automatically resets after overload is removed
Surge protection type
Output voltage shutdown; restart when voltage returns within the setting range (category C per GOST IEC 61204)
Connection type
Screw connection
Controlled regulated output voltage
Yes
Width
70 мм
Width in modular units
3
Dielectric strength input-output
3
Dielectric strength input-housing
1.5
Output-to-housing dielectric strength
0.5
