ONI (Группа IEK)
Power supply OPS 220V AC/24V DC 5A 120W ONI OPS-DC24-120B
SKU: OPS-DC24-120B
ETIM: EC002540
183,240 ₽
Get back 1,832 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Order multiple: 24 шт
Analogues by specifications
No description available
2nd output voltage stage to
24 В
2nd output voltage step from
24 В
Weight
0.52 кг
Load influence
1.0
Influence of supply voltage
0.5
Busbar mounting possible
Yes
Hold-up time at 100% load - input voltage 115 V
10
Hold-up time at 100% load - input voltage 230V
20
Settling time at 100% load and 115 V input voltage
3000
Settling time at 100% load and 230 V input voltage
1200
Height
124 мм
Height
124 мм
Altitude above sea level
≤ 6000
Output power
120 В.А
Output power
120 Вт
Output voltage 1 at
24 В
Output voltage 1 from
24 В
Depth
119 мм
Input voltage range
AC (90...264); DC (127...370)
Output current range
0...5.00
Output voltage setting range
24...28
Overvoltage protection tripping range
28.8...31.2
Frequency range
47...63
Short-circuit protection
Yes
Insulation per GOST 12-2-091
Reinforced
Efficiency
88
Overvoltage category
2
Number of supply lines
4
Maximum output current 1
5 А
Modular design
No
Rated power at air temperature 25°C
120
Rated DC output voltage
24
Rated AC mains supply voltage 50 Hz to
264 В
Rated AC 50 Hz mains supply voltage from
220 В
Rated DC supply voltage to
370 В
Rated DC supply voltage from
- В
Rated output current
5.00 А
Relative air humidity
20...90%
Peak inrush current at 230V input voltage
35
Output current limiting threshold
105...130
Power consumption
- кВт
Max. permissible output voltage deviation
1
Connection capability
0.5...6
Supply voltage current type
AC/DC
Self-current consumption
≤ 0.035
Insulation resistance at 500V input-output
10
Insulation resistance at 500 V input-housing
10
Insulation resistance at 500V output-housing
10
Mounting method
DRA (on DIN rail)
Pollution degree
2 per GOST IEC 60947-1
IP protection rating
IP20
Temperature coefficient
±0.03% (category C per GOST IEC 61204)
Overload protection type
output current limiting; automatically resets after overload is removed
Surge protection type
Output voltage shutdown; restart when voltage returns within the setting range (category C per GOST IEC 61204)
Connection type
Screw connection
Controlled regulated output voltage
Yes
Width
45 мм
Width in modular units
3
Dielectric strength input-output
3
Dielectric strength input-housing
1.5
Output-to-housing dielectric strength
0.5
