ONI (Группа IEK)
Power supply OPS 220V AC/48V DC 240W ONI OPS-DC48-240B
SKU: OPS-DC48-240B
ETIM: EC002540
22,800 ₽
Get back 228 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Analogues by specifications
No description available
Load influence
1.0
Influence of supply voltage
0.5
Busbar mounting possible
Yes
Height
128 мм
Height
128 мм
Altitude above sea level
< 6000
Output power
240 Вт
Output power
240 В.А
Output voltage 1 at
48 В
Output voltage 1 from
48 В
Depth
132 мм
Input voltage range
AC (90...264); DC (127...370)
Output current range
0...5.00
Output voltage setting range
48...56
Overvoltage protection tripping range
53.0...68.0
Frequency range
47...63
Short-circuit protection
Yes
Insulation per GOST 12-2-091
Reinforced
Efficiency
88
Overvoltage category
2
Maximum output current 1
5 А
Modular design
No
Rated power at air temperature 25°C
240
Rated DC output voltage
48
Rated AC 50 Hz mains supply voltage from
220 В
Rated DC supply voltage from
- В
Rated output current
5.00 А
Relative air humidity
20...90%
Peak inrush current at 230V input voltage
60
Output current limiting threshold
110...126
Power consumption
- кВт
Power consumption
0 Вт
Max. permissible output voltage deviation
1
Connection capability
0.5...6
Supply voltage current type
AC/DC
Self-current consumption
< 0.035
Insulation resistance at 500V input-output
10
Insulation resistance at 500 V input-housing
10
Insulation resistance at 500V output-housing
10
Mean time between failures at 25°C
300
Pollution degree
2 per GOST IEC 60947-1
IP protection rating
IP20
Temperature coefficient
±0.03% (category C per GOST IEC 61204)
Overload protection type
Constant output voltage maintenance
Surge protection type
Trip with auto-reset
Controlled regulated output voltage
Yes
Width
70 мм
Width in modular units
3
Dielectric strength input-output
3
Dielectric strength input-housing
1.5
Output-to-housing dielectric strength
0.5
