КЭАЗ
OptiPower LRS 100-12 8.5A panel power supply KEAZ 328878
SKU: 328878
ETIM: EC002540
1108 ₽
Preorder
OptiPower LRS series power supply units are designed to supply various electronic devices with stabilized 12V or 24V DC voltage. The units are switching voltage converters with protection against overload, overheating, and short circuit at the output.
| 2nd output voltage stage to | 0 В |
| 2nd output voltage step from | 0 В |
| Wall mounting possible | No |
| Busbar mounting possible | No |
| Height | 97 мм |
| Output power | 102 Вт |
| Output voltage 1 at | 12 В |
| Output voltage 1 from | 12 В |
| Depth | 30 мм |
| Short-circuit protection | Yes |
| Maximum output current 1 | 8.5 А |
| Maximum output current 2 | 0 А |
| Modular design | No |
| Mounting height | 97 мм |
| Rated output voltage 1 | 12 В |
| Rated output voltage 2 | 0 В |
| Rated output voltage 3 | 0 В |
| Rated AC mains supply voltage 50 Hz to | 264 В |
| Rated AC 50 Hz mains supply voltage from | 85 В |
| Rated DC supply voltage to | 373 В |
| Rated DC supply voltage from | 120 В |
| Rated output current 1 | 8.5 А |
| Rated output current 2 | 0 А |
| Rated output current 3 | 0 А |
| Power consumption | 120 Вт |
| Adjustable output voltage | Yes |
| Supply voltage current type | AC/DC |
| Stabilized | Yes |
| IP protection rating | IP20 |
| Connection type | Screw connection |
| Controlled regulated output voltage | Yes |
| Width | 129 мм |
| Width in modular units | 1 |
| Installation width | 129 мм |
