Rexant
Power supply unit stabilized 12V 2A internal installation DC-494 Rexant 34-0494
SKU: 34-0494
ETIM: EC002540
1,654 ₽
Get back 16 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Analogues by specifications
Distinctive features
- Electronic short circuit protection
- Automatic recovery of Uout after short circuit removal
- Overcurrent protection
- Consumer overvoltage protection
- Input overvoltage protection
- Unlimited time in short circuit state
- Output voltage indication available
Technical characteristics
- Input voltage: Uin. AC 160-242V
- Output voltage, adjustable: Uout = 12-14.5V
- Rated output current: Inom = 2A
- MTBF, not less than: 100000 hours
- Housing type: Plastic, non-detachable housing, for concealed installation
- Dimensions: 147x40x30mm
- Package dimensions: 150x50x45mm
2nd output voltage stage to
0 В
2nd output voltage step from
0 В
Wall mounting possible
Yes
Busbar mounting possible
Yes
Height
40 мм
Output power
24 Вт
Output voltage 1 at
12 В
Output voltage 1 from
12 В
Depth
30 мм
Short-circuit protection
Yes
Maximum output current 1
2 А
Maximum output current 2
0 А
Modular design
No
Mounting height
0 мм
Rated AC mains supply voltage 50 Hz to
242 В
Rated AC 50 Hz mains supply voltage from
160 В
Rated DC supply voltage to
12 В
Rated DC supply voltage from
12 В
Power consumption
11.64 Вт
Adjustable output voltage
No
Supply voltage current type
Direct current (DC)
Stabilized
Yes
IP protection rating
IP30
Connection type
Screw connection
Controlled regulated output voltage
Yes
Width
147 мм
0
★★★★★
0 reviews
No reviews yet. Be the first!
Leave a review
