Distribution block, screw clamp, 1x120 sq.mm, 2x35 sq.mm, 5x16 sq.mm, 4x10 sq.mm POD-250 DKC
SKU: POD-250
ETIM: EC000276
2,202 ₽
Get back 22 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Analogues by specifications
Stock by warehouse
POD-250 distribution block with screw terminal is used for connecting and distributing bare or ferruled flexible conductors in electrical panels. Mounting on a 35 mm DIN rail or a PCB. A side pin ensures interlocking of the blocks. Key information is printed on the distribution block cover, and there is a slot for NUTB5 marking. The kit includes colored plastic markers (blue, green, red, yellow) and self-adhesive ones (L1, L2, L3, N, ground, circle). The housing is made of polyamide with flammability class V0 UL-94. Protection degree – IP20. Color – gray, 1 inlet with cross-section 35-120 mm2, 11 connection points (terminals) with nominal conductor cross-section 2.5-35 mm2. Dimensions (H×W×D) – 51.5×49×96.5 mm.
Version tested for explosion protection "Ex e"
No
Internally linked levels
No
Minimum possible mounting height
52 мм
Length
96.5 мм
Length
96.5 мм
Flammability class of insulation material in accordance with UL57
V0
Number of terminals per level
12
Number of poles
12
Number of levels
1
Housing insulation material
Thermoplastic
Rated voltage
1000 В
Rated current In
250 А
Closing plate can be fitted if required
No
Operating temperature
105 град.C
Operating temperature from
-40 град.C
Connection position
Side
With protection against contact with live parts
Yes
Core cross-section
120 кв.мм
Stranded wire cross-section with ferrule
2.5...25 мм²
Flexible stranded conductor cross-section up to
120 кв.мм
Stranded flexible conductor cross-section from
2.5 кв.мм
Solid conductor cross-section to
120 кв.мм
Solid conductor cross-section from
2.5 кв.мм
Extra-fine-stranded flexible conductor cross-section without ferrule, from
2.5...120 кв.мм
Mounting method
DIN rail 35 mm
Electrical connection type 1
Screw connection
Electrical connection type 2
Screw connection
Colour
Grey
Color
Grey
Width/connection pitch
49 мм
