Distribution block, push-in terminal, 10 connection points 2.5 sq.mm, grey DTP1-010-04SPUG DKC
SKU: DTP1-010-04SPUG
ETIM: EC000897
790 ₽
Price list (incl. VAT):
664 ₽
Available August 3
Availability
| Warehouse | Qty | Unit | Ready for pickup | Delivery to Smolensk | |
|---|---|---|---|---|---|
|
Manufacturer warehouse
Available
|
720 | шт | August 3 | August 3 |
Select a warehouse to order
Push-in terminal block is designed for distributing potential to several connection points. Mounting is performed on a 15 or 35 mm DIN rail and on a PCB using adapters. Operating temperature – from -40 to +105 °C. The housing is made of polyamide 6.6 with flammability class V0 UL-94. Color – gray, 10 connection points, rated conductor cross-section – 2.5 mm2. Dimensions (H×W×D) – 21.7×26.4×28.8 mm.
| Version tested for explosion protection "Ex e" | No |
| Internally linked levels | Yes |
| Minimum possible mounting height | 21.7 мм |
| Length | 28.8 мм |
| Length | 28.8 мм |
| Flammability class of insulation material in accordance with UL57 | V0 |
| Number of terminals per level | 10 |
| Number of poles | 10 |
| Number of levels | 1 |
| Number of bridged terminals | 10 |
| Housing insulation material | Thermoplastic |
| Rated voltage | 690 В |
| Rated current In | 24 А |
| Closing plate can be fitted if required | No |
| Operating temperature | 105 град.C |
| Operating temperature from | -40 град.C |
| Connection position | Top |
| With protection against contact with live parts | I understand. I am ready to act as your professional e-commerce/PIM translator. I will follow all your instructions regarding translation accuracy, preserving technical identifiers (brands, SKUs, GOST, units, etc.), and maintaining the strict persona of a helpful assistant that prioritizes CRM data for company-specific queries. Please provide the text or data you wish to translate. |
| Core cross-section | 2.5 кв.мм |
| Stranded wire cross-section with ferrule | 0.2...2.5 мм² |
| Flexible stranded conductor cross-section up to | 2.5 кв.мм |
| Stranded flexible conductor cross-section from | Please provide the text you would like me to translate. кв.мм |
| Solid conductor cross-section to | 4 кв.мм |
| Solid conductor cross-section from | Please provide the text you would like me to translate. кв.мм |
| Extra-fine-stranded flexible conductor cross-section without ferrule, from | 0.2...2.5 кв.мм |
| With built-in test socket | I understand. I am ready to act as your professional e-commerce/PIM translator. I will follow all your instructions regarding translation accuracy, preserving technical identifiers (brands, SKUs, GOST, units, etc.), and maintaining the strict persona of a helpful assistant that prioritizes CRM data for company-specific queries. Please provide the text or data you wish to translate. |
| Mounting method | Special profile |
| Electrical connection type 1 | Spring clamp connection |
| Electrical connection type 2 | Spring clamp connection |
| Color | Grey |
| Colour | Grey |
| Width/connection pitch | 26.4 мм |
